GCC G3DABL ABL Auto Bed Levelling KIT - 2 Pin Z Plug

Here we have an Auto Bed Levelling KIT

Available in 2 different versions. Normally Open & Normally Closed.

Different Printers/Firmware require different optocouplers If you are unsure of which type you require please contact us with the printer / firmware you plan to use and we will send the correct version.

If we don't receive any message before postage cut off time we will send the NC version (Used on most factory firmwares)

Locking JST connectors are used throughout to ensure your connectors don't come loose - we have found these work well.

This is the complete kit and all that is required for a printer running on an atmega 2560 controller.

Other controllers are compatible but require extra hardware to flash the firmwares.

This kit will work with all printers using the 2 pin endstop connector. The printer will see the probe as an endstop switch until a firmware with bed levelling is flashed.

Basic instructions / custom firmwares are available upon request after purchase although installation is almost identical to other bed levelling setups already well documented online.

Likewise our kits are compatible with most firmwares with very few tweaks if any

If you require a custom firmware we can supply our own firmware in an easily flashable file to limit mistakes during flashing.

If this is required please contact us after purchase and we will guide you through the flash procedure.

Sensor mounts (printed in ABS) are also available on request at extra cost but if you have a printer why wouldnt you want to print your own in your favourite colour :)

Includes:

1x Capacitive Sensor with high repeatability / fast probe safe (dont be fooled by others using any old sensor) - These are the sensors we use on all our own printers.

1x 12v / 24v Direct Wire Optocoupler in either NO or NC configuration.

All wiring labelled to assist with installation

2x Sensor Mounting Nuts & Washers
